Description
High-Performance LED End-Outline Marker Light for Trucks, Trailers, Buses and Commercial Vehicles
JOKON 12.0020.300 is the original SPL 2025 LH LED End-Outline Marker Light with integrated Side Marker Light (SML), designed for trucks, trailers, buses and commercial vehicles operating on 9–32V electrical systems.
Featuring a flexible 90° mounting bracket, a fully sealed IP67 housing, and a 500 mm cable, this lamp offers outstanding durability and reliable operation in demanding environments.
Ideal for trucks, trailers, semi-trailers, buses, agricultural machinery and special vehicles.
Key Features
- High-efficiency LED technology
- End-outline marker light with integrated Side Marker Light (SML)
- Left-hand version (LH)
- Suitable for 9–32V electrical systems
- Very low power consumption (1.8 W)
- Flexible 90° mounting bracket
- Waterproof sealed construction
- Ready for direct installation
- 500 mm connection cable
- IP67 waterproof and dustproof
- Lightweight: only 0.16 kg
- Operating temperature: -20°C to +50°C
- ECE E13 approved
Technical Specifications
| Specification | Value |
|---|---|
| Brand | JOKON |
| Reference | 12.0020.300 |
| Model | SPL 2025 LH |
| Voltage | 9–32 V DC |
| Power Consumption | 1.8 W |
| Light Source | LED |
| Function | End-Outline Marker Light + Side Marker Light (SML) |
| Version | Left-hand (LH) |
| Cable Length | 500 mm |
| Mounting | Flexible 90° bracket |
| Protection Rating | IP67 |
| Operating Temperature | -20°C to +50°C |
| Weight | 0.16 kg |
| Approval | E13-35831 |
Applications of JOKON 12.0020.300
Suitable for:
- Trucks
- Semi-trailers
- Trailers
- Buses
- Agricultural machinery
- Construction equipment
- Commercial vehicles
- Special vehicles
Why Choose JOKON?
For decades, JOKON has been one of Europe’s leading manufacturers of OEM vehicle lighting, renowned for exceptional reliability, long service life and premium quality.
The SPL 2025 series combines modern LED technology, extremely low power consumption and robust construction, making it ideal for professional applications.
What’s Included
- 1 × JOKON SPL 2025 LH LED End-Outline Marker Light
- Integrated 500 mm cable
- Flexible mounting bracket
